At the heart of the closed cab goods transport tricycle is a 200-350cc single-cylinder water-cooled engine, one of the highest-displacement options in the semi-enclosed cargo tricycle segment. Engineers recalibrated the power curve specifically for heavy-duty operation, concentrating torque reserve in the low-to-mid RPM range for stronger traction during takeoff and hill climbs. It handles 15°-20° slopes smoothly at full load without constant gear shifting, delivering consistent power that eliminates the "half-climb power drop" common to smaller-displacement models. The water cooling system is paired with an oversized radiator for markedly higher heat dissipation efficiency than equivalent air-cooled units. Even after hours of continuous heavy-load driving in summer heat, the engine shows no noticeable thermal fade and maintains steady power output. It also reduces component wear caused by high temperatures, greatly extending overhaul intervals and lowering long-term operating costs.
Advantage
The frame is fully welded from thickened steel, with reinforced structures at high-stress points such as cargo bed stringers and main chassis beams, achieving heavy-duty torsional and bending strength. It resists frame deformation and weld cracking even under long-term hauling of cement, gravel and grain. The cargo bed features reinforced steel side rails and an embossed anti-slip floor that keeps heavy loads from shifting during transport. Rail height is optimized for both manual handling and small machinery loading, streamlining daily pickup and drop-off. The running gear is matched with hydraulic front shock absorbers and a multi-leaf heavy-duty rear spring pack, keeping the body stable and minimizing jolts when driving over potholes and rough roads at full load. Both axles run on deep-tread heavy-duty off-road tires with thick carcasses and aggressive tread patterns for strong grip. They perform reliably on construction dirt roads, muddy post-rain tracks and rural gravel paths, with strong puncture resistance and minimal skid risk. The hydraulic braking system delivers linear, powerful braking force for confident downhill hauling with heavy cargo, with minimal fade under repeated use. A parking brake adds extra security for stops on slopes.
Product Specifications
|
Certification |
CCC |
Use For |
Cargo |
|
Driving Type |
Motorized |
Payload Capacity |
≥400kg(≥881.85lb) |
|
Maximum Speed |
50-70Km/h(31.07-43.50mph) |
Power |
> 1000W |
|
Grade Ability |
15-20° |
Passengers |
1 |
|
Displacement |
201 - 350cc(6.80-8.45fl.oz) |
Voltage |
12V |
|
Brake System |
Front drum+Rear drum |
Body Type |
Open |
|
Curb Weight |
≥500kg(≥1102.31lb) |
Fuel Tank Capacity |
10-20 L(2.64-5.28gal) |
|
Type |
Right three-wheeled motorcycle |
Place of Origin |
Chongqing, China |
|
Tire Size |
5.5-12/5.5-12 |
Brand |
BEYEE |
|
Size |
Standard Size |
Product name |
Three Wheel Tricycle |
|
Brand |
BEYEE |
Engine |
200-350cc,water-cooling |
|
Cargo box size |
2m*1.35m |
Front Shock Absorber |
Hydraulic spring(Double) |
|
Front/Rear Tire |
5.00-12 |
Wheels Type |
Three |
|
Rear Axle |
Intergral booster drum |
Rear Brake |
Hydraulic |
|
Chassis |
50*100 |
||
why choose us?
With a strong load-bearing capacity, it is suitable for hauling goods, express delivery, and transporting agricultural products. It is highly durable, suitable for harsh environments such as rural areas and mountain roads. It is economical, with the electric version offering low operating costs and simple maintenance. The enclosed cab enhances driving comfort, making it especially suitable for rainy southern regions or cold northern regions.
